Before the installation of the basketball stand, remove all the packages according to the details of the main components of the basketball stand.

1. Place the basketball frame box on the center line of the court 1m away from the outside of the end line of the court × 40 hexagon bolt, spring washer and enlarged flat washer connect the lower end of the column assembly with the base.

2. Tilt the column and base forward at a certain angle, place the extension arm on the upper end of the column, and connect the vertical arm and extension arm with the tile.

3. After the rear pull rod is connected with the connecting pipe with the adjusting bolt, the upper end is connected with the shaft at the rear end of the extension arm with the bushing; Then use M12x60 screws to connect the other end of the rear pull rod with the box ear.

4. Connect the basketball frame backboard ear with the backboard with M10x20 countersunk bolt, and then two people will lift the backboard, first use M12 × 70 bolts, spring washers and flat washers connect the hoop and backboard with the extension arm, and then use the backboard adjusting bolts to connect and fasten the upper pull rod (Figure 3) with the backboard ear; Put the connected end of the upper pull rod under the fixed pressing plate and screw M10 × 30 Hexagon head bolt.

5. Raise the basketball stand, open the cover plate of the base, put the counterweight (or stone) into the base, then cover the cover plate, tighten all the bolts and nuts of the basketball stand, and the basketball stand is installed.

6. Put the protective sleeve of the basketball frame on the base and the column, and assemble the buckle firmly.
